Kod: C61355
Producent: Claypaky
700 W lampa zapewnia jasność równą, jeśli nie większą, niż inne oprawy na lampach wyższej mocy. Alpha Spot HPE 700 oferuje funkcje i efekty graficzne do tej pory dostępne tylko w jednostkach większej mocy, w tym elektronicznie ustawiany zoom 15° -35° oraz hybrydowy dimmer elektroniczny / mechaniczny. Alpha 700 HPE oferuje także dużą prędkość i precyzję ruchu. Cicha praca, kompaktowa i lekka obudowa, zaawansowane funkcje oraz ekologiczny tryb pracy umożliwiający przełączenie oprawy w tryb lampy 400W sprawiają, że urządzenia doskonale sprawdza się wśród firm rentalowych nadając się do niemalże wszystkich zastosowań...
100 - 240V 50/60Hz
Automatic power supply switching
1050VA at 230V 50Hz (PFC electronic ballast)
700 W discharge lamp:
- Type: Philips MSR Gold 700/2 MiniFastFit
- Cap: PGjX28
- Color Temperature: 7,200 K
- Fluminous Flux: 50,000 lm
- Average Life: 750 h
Elliptic reflector with high luminous efficiency
Electronic linear zoom 14,7°- 35° (47° with frost)
Electronic Focusing
"Uniform field lens" on dedicated channel, that allows the passage, at will, from “hot spot” to uniform field
CMY Color Mixing
Color Wheel with 8 pure and selected color filters + open
CTO 2500 K and CTO 3200 K filters (on color wheel
1 Rotating Gobo Wheel, with 7 bidirectional and indexable gobos (Ø 25,7mm)
1 wheel with 8 fixed gobos (Ø 31,5mm), at variable rotation
Selectable "Gobo shake" function.
"Morphing" effect.
Fixed and rotating gobos are easily interchangeable.
1 rotating prism (5 facet).
Frost with adjustable projection angle.
High-Speed Mechanical Iris.
A new conception 0-100% Dimmer + dimmer fine on dedicated channel.
Stop/strobe effect.
Max 29 DMX 512 control channels
DMX protocol signal: USITT DMX 512
Display: Graphic LCD backlit b/w Display
Pan/Tilt Resolution: 16 bit
Gobo Indexing Resolution: 16 bit
Dimmer Resolution: 16 bit
Movement control: vectorial
DMX signal connection: 3 and 5 pole XLR input and output
Software upload through DMX input
Aluminium structure with die-cast plastic cover.
Two side handles for transportation.
PAN and TILT lock for transport and maintenance.
Angle:
- PAN = 540°, TILT = 250°
Max Speeds:
- PAN = 3.77 sec (Normal Mode) - 3.20 sec (Fast Mode)
- TILT = 2.19 sec (Normal Mode) - 1.89 sec (Fast Mode)
Resolution:
- PAN = 2.11°, PAN FINE = 0.008°
- TILT = 0.98°, TILT FINE = 0.004°
Automatic repositioning of PAN and TILT after accidental movement not controlled by control unit.
Long life self-charging buffer battery.
Pre-set macros.
"ENERGY SAVING" function: with the stop or total dimmer effect on, or with all the CMY filters full (black), consumption cut by 50%.
ON/OFF lamp control from the lighting desk.
Function reset from the lighting desk.
"AUTOTEST" function from menù
ETHERNET Ready.
Electronic monitoring with status error
Cooling system monitoring
DMX level monitoring on all channels
Internal data transmission diagnostics
Firmware Upgrade with no power
Firmware upload from another fixture
Bipolar circuit breaker with thermal protection.
Automatic break in power supply in case of overheating.
Forced ventilation with axial fans.
Functions in any position.
Hanging system: with fast-lock omega clamps (1/4 turn) on the base
In conformity with the European Union Low Voltage Directive 2006/95/CE and Electromagnetic compatibility Directive 2004/108/CE.
This product is available, on demand, with cETLus Listed Mark, that complies with the UL 1573 and CSA C22.2 No. 166 standards.
22.9 Kg (50 lbs 6 ozs)
