Kod: C61078
Producent: Claypaky
The Alpha Wash Halo 1200 combines extraordinary brightness with the versatility of a 1200 W 80 V (3300 K) halogen lamp, which can be used with any power supply voltage required. It has a 14°- 64° linear zoom, CMY colour mixing, linear frost effect, electronic dimmer, adjustable ovalizer filter and stop/strobe. Its motorized top hat is an extraordinary device that ensures perfect light beam control. The Alpha Wash Halo 1200 is designed for the most professional lighting sectors. It combines a high-quality spotlight with the typical advantages of a halogen lamp: uniform light, warm shade of colour and gradual dimmer.
Kategoria: ruchome głowy , wash
200 - 240V 50/60Hz
100 - 120V 50/60Hz
The power supply can be changed over with the built-in selector.
1400 VA at 230 V 50 Hz.
1200W, 80V Halogen Lamp:
- Type: Philips Halogen 7009Z
- Cap: G22
- Color temperature: 3,250 K
- Luminous flux: 36,000 lm
- Average life: 200 h
Elliptic reflector with high luminous efficiency
Electronic linear Zoom 14°- 64°
Fresnel Lens: diameter 200 mm, focal length 140 mm.
Motorized Top Hat for a perfect beam control
CMY Color Mixing
| Supergel Rosco (n°) | % Cyan | % Magenta | % Yellow |
| 68 | 0 | 53.0 | 100 |
| 26 | 100 | 0 | 0 |
| 21 | 100 | 26.0 | 0 |
| 74 | 0 | 29.0 | 100 |
| 79 | 0 | 40.0 | 100 |
| 20 | 100 | 43.0 | 0 |
| 19 | 100 | 19.5 | 0 |
| 15 | 100 | 55.0 | 0 |
| 90 | 0 | 100 | 0 |
| 80 | 0 | 48.0 | 100 |
Frost with linear variation.
Indexable ovalizer.
0-100% electronic dimmer with an extremely gradual dimming and uniform color temperature field.
Stop / strobe effect.
Max 17 DMX 512 control channels
DMX protocol signal: USITT DMX 512
Display: Graphic LCD Display
Pan/Tilt Resolution: 16 bit
Movement control: vectorial
DMX signal connection: 3 and 5 pole XLR input and output
Software upload through DMX input
Aluminium structure with die-cast plastic cover.
Two side handles for transportation.
PAN and TILT lock for transport and maintenance.
The body of the projector can be coloured, choosing from the range of 14 colours available (minimum order: 6 pieces)
Angle:
- PAN = 450°, TILT = 252°
Max Speeds:
- PAN = 4.0 sec. (360°)
- TILT = 3.2 sec. (252°)
Resolution:
- PAN = 1.76°, PAN FINE = 0.007°
- TILT = 0.98°, TILT FINE = 0.004°
Automatic repositioning of PAN and TILT after accidental movement not controlled by control unit.
Long life self-charging buffer battery.
Pre-set macros.
"ENERGY SAVING" function: with the stop or total dimmer effect on, or with all the CMY filters full (black), consumption cut by 50%.
115/230 V switchable power supply.
ON/OFF lamp control from the lighting desk.
Function reset from the lighting desk.
"HELP", "MEMO", "AUTOTEST" functions
Possibility to upgrade the software through the DMX 512 input.
ETHERNET connection.
Electronic control on each parameter.
DMX level monitoring on each channel.
Feedback information for each sensor and encoder.
Electronic repositioning of the effects
Bipolar circuit breaker with thermal protection.
Automatic break in power supply in case of overheating.
Forced ventilation with axial fans.
Functions in any position.
Hanging system: with fast-lock omega clamps (1/4 turn) on the base
In conformity with the European Union Low Voltage Directive 2006/95/CE and Electromagnetic compatibility Directive 2004/108/CE.
29,5 Kg (64lbs 14 ozs)
