Kod: CP C61310
Producent: Claypaky
The Alpha Profile 1500 is a cutting-edge professional beam shaper that combines the high output power of a 1500 W lamp with an exclusive framing system (patented) capable of any shape. It features an astonishing 1:9 ratio zoom, with a breathtaking speed, that makes it suitable to both short and long distance applications. by Clay Paky.
It is extremely bright, very silent and has advanced electronics and software. It comes with a comprehensive range of graphic effects, the innovative Stay-Sharp-Zoom function allowing automatic focusing and the smart Zoom-Tracking-Diffuser for a linear beam softening. The Alpha Profile 1500 is a valuable resource for designers working in demanding lighting environments.
Kategoria: ruchome głowy , beam
200 - 240V 50/60Hz
2.000VA at 230V 50Hz (PFC electronic ballast).
1500W discharge lamp:
- Type: Osram Lok-it 1500W
- Cap: PGJ50
- Color temperature: 6,000 K
- Luminous flux: 135,000 lm
- Average life: 750 h
Elliptic reflector with high luminous efficiency
4° standard beam
Electronic focusing (patented)
CMY Color Mixing
6-color wheel + open.
3200K CTO filter.
1 Rotating Gobo wheel with 6 bidirectional and indexable gobos (Ø 37,5 mm)
1 wheel with 8 fixed gobos (Ø 31,5mm), at variable rotation
Selectable "Gobo shake" function.
All the fixed and rotating gobos are easily interchangeable
3 rotating prisms (5 facet, 3D effect, comet effect)
3 linear frosts on dedicated channels
Special high speed mechanical iris
Hybrid 0-100% dimmer (electronic + mechanical)
Stop / strobe effect.
Max 28 DMX 512 control channels
DMX protocol signal: USITT DMX 512
Display: Graphic LCD backlit b/w Display
Pan/Tilt Resolution: 16 bit
Gobo Indexing Resolution: 16 bit
Dimmer Resolution: 16 bit
Movement control: vectorial
DMX signal connection: 3 and 5 pole XLR input and output
Software upload through DMX input
Aluminium structure with die-cast plastic cover.
Two side handles for transportation.
PAN and TILT lock for transport and maintenance.
Angle:
- PAN = 540°
- TILT = 252°
Maximum speeds
- PAN = 4.0 sec (360°)
- TILT = 3.2 sec (252°)
Resolution:
- PAN = 2.11°
- PAN FINE = 0.008°
- TILT = 0.98°
- TILT FINE = 0.004°
Automatic repositioning of PAN and TILT after accidental movement not controlled by control unit.
Long life self-charging buffer battery.
Pre-set macros.
Function reset from control unit
"ENERGY SAVING" function: with the stop or total dimmer effect on, or with all the CMY filters full (black), consumption cut by 50%.
ON/OFF lamp control from the lighting desk.
Function reset from the lighting desk.
"AUTOTEST" function from menù
ETHERNET Ready.
Electronic monitoring with status error
Cooling system monitoring
DMX level monitoring on all channels
Internal data transmission diagnostics
Firmware Upgrade with no power
Firmware upload from another fixture
Bipolar circuit breaker with thermal protection.
Automatic break in power supply in case of overheating.
Forced ventilation with axial fans.
Functions in any position.
Hanging system: with fast-lock omega clamps (1/4 turn) on the base
In conformity with the European Union Low Voltage Directive 2006/95/CE and Electromagnetic compatibility Directive 2004/108/CE.
This product is available, on demand, with cETLus Listed Mark, that complies with the UL 1573 and CSA C22.2 No. 166 standards.
40 Kg (88.18 lbs)
