Stage Scan is Clay Paky's most sophisticated moving mirror fixture. It has an extremely rich set of graphic effects and a sophisticated beam colouring system. Its exclusive Multi-Step-Zoom system provides a wide range of beam angles. It is a sound reliable light designed specifically for all stage lighting applications that need faster beam movement than can normally be achieved with a moving head.
Category: light effects
• 230V 50Hz
• 240V 50Hz
• 208V 60Hz
• 200V 50Hz
• 200V 60Hz
1500VA at 220V 50Hz (PFC 140µF).
1200W discharge lamp:
- Type: HMI 1200W/GS
- Cap: SFc 15,5-6
- Color Temperature: 6.000 K
- Luminous Flux: 110.000 lm
- Average Life 750 h
- Hot Restrike
Elliptic reflector with high luminous efficiency
MSZ (Multi Step Zoom) with the following beam angles: 13°; 14,5°; 16°; 18°; 21°; 25°
Electronic focusing
Color Mixing CMY
A wheel with 7 interchangeable colors and special effects (Ø 47mm), including concentric-color filters, 4-color filters, CTO, CTB, UV filter
1 wheel with 4 fixed and interchangeable metallic gobos (Ø 66mm)
1 wheel with 4 rotating, indexable and interchangeable gobos, including two glass gobos (Ø 51,8mm)
10 additional gobos, supplied
1 wheel with 4 rotating and indexable prisms
Fixed prism
High-speed iris
0-100% Dimmer with instantaneous beam stop
1 - 7 flash/sec. strobe, black-out 70 msec.
Frost wheel with 3 frost filters, including the exclusive Clay Paky "flou effect"
16 or 17 DMX 512 control channels
DMX signal connection: 3 and 5 pole XLR input and output
In die-cast and extruded aluminium
Epoxy powder painting
Four side handles for transportation
Head rotable through 360° on projection housing
Graduated scale for easy and accurate positioning
Anchorage for safety wire
Mirror of ultra-high luminous efficiency
Variable speed of rotation. Maximum values:
- PAN = 0.4 sec (150°); TILT = 0.3 sec (110°)
Continuous and uniform movement. Resolution:
- PAN = 0.6° (150°); TILT= 0.4° (110°)
Steel bracket with expody powder painting
Six installation positions, 25mm (1") apart.
Bracket adjustable through 100°, with graduated scale to assist positioning
Anchorage for safety wire
Automatic break in power in case of overheating
Automatic disconnection of the power supply at the opening of the re-lamping cover
Forced ventilation with axial fans.
Functions in any position.
In conformity with the European Union Low Voltage Directive 2006/95/CE and Electromagnetic compatibility Directive 2004/108/CE.
40 Kg (88 lbs)
3,1 Kg (6lbs 13 oz) mirror adapter
safety cable Ø 4mm, lenght 1000mm
48-51mm, max 300 Kg hook for truss
Adaptor kit for dichroic/photographic gobos Ø 51.8 mm (for use on fixed gobo wheel)
Adaptor kit holder for dichroic/photographic gobos Ø 45 mm for use on fixed gobo wheel
Adaptor kit holder for dichroic/photographic gobos Ø 51,8 mm for use on rotating gobo wheel
Adaptor kit holder for dichroic/photographic gobos Ø 45 mm for use on rotating gobo wheel
