Code: GRV AL2306SE
Griven
Category: bars
Light Source:
- 5 | 10 | 12 points LED RGB
- Source life: 50,000h
- Dimming facility: 1-100%
Optics:
- narrow
- medium
- wide
- elliptical
- elliptical wide
- wall washer
LED color
- RGB: Red-Green-Blue
Control System
- Module: 4 channels of DMX- 512 protocol
- On-board Dip Switch set for digital data assignment and stand alone operation control
- Master-Slave mode
Electrical specification
- Power Supply: 100-277 V / 50- 60 Hz
- Power consumption: 20W | 40W | 45W
Housing:
- Die cast aluminium body
- Scratch resistant polyester grey finish, protected against UV deterioration and general corrosion
- Easy mounting system
- IP67 protection rating
- External operating limits: -40°C to 50°C
Weight:
- 2.9kg | 4.7 kg | 5kg
