Code: C11072
Claypaky
Golden Scan 4 is the latest member of the legendary Clay Paky Golden Scan family. It is an effective bright motorized fixture with a powerful 1200 W lamp and excellent effects as standard. It provides great reliability, a perfectly clear beam, great simplicity of use and matchless mirror speed at a competitive price.
Category: light effects
230 V 50 Hz
240 V 50 Hz;
208 V 60 Hz;
200 V 50 Hz;
200 V 60 Hz
Version without PFC (standard): 3,000 VA at 230V 50 Hz
Version with PFC: 1,500VA at 230V 50 Hz (rephasage 140µF only on request).
1200W discharge lamp:
- Type: HMI 1200W/GS
- Cap: SFc 15,5-6
- Color Temperature: 6.000 K
- Luminous Flux: 110.000 lm
- Average Life 750 h
- Hot Restrike
Elliptic reflector with high luminous efficiency
Standard Lens: 1:2.5/ 250 mm (11°)
Optional Lens: 1:3.3/300 mm (9°)
Wide-angle Optional lens: 1:1.6/ 160 mm (to be inserted inside the projector)
A wheel with 7 color filters (Ø 47mm) + open
2 color temperature correction filters
Wheel with 4 rotating gobos (Ø 66mm), at variable speed , indexable on 540°
Wheel with 4 fixed gobos (Ø 66mm)
Fixed prism (4 facet)
0-100% Dimmer
Stop-strobe (1-7 flash / sec)
Fixed frost
10 or 12 DMX 512 control channels
DMX signal connection: 5 pole XLR input and output
In die-cast and extruded aluminium
Epoxy powder painting
Four side handles for transportation
Head rotable through 360° on projection housing
Anchorage for safety wire
Mirror of ultra-high luminous efficiency
Excursion:
- PAN = 150°
- TILT = 110°
Max Speed:
- PAN = 0.4 sec. (150°)
- TILT = 0.3 sec. (110°)
Resolution:
- PAN = ±0.3°
- PAN FINE = ±0.0011°
- TILT = ±0.2°
- TILT FINE = ±0.0007°
Steel bracket with expody powder painting
Six installation positions, 25mm (1") apart.
Bracket adjustable through 100°, with graduated scale to assist positioning
Anchorage for safety wire
Automatic break in power in case of overheating
Automatic disconnection of the power supply at the opening of the re-lamping cover
Forced ventilation with axial fans
Functions in any position.
In conformity with the European Union Low Voltage Directive 2006/95/CE and Electromagnetic compatibility Directive 2004/108/CE.
37 Kg
3,1 Kg (mirror adapter)
safety cable Ø 4mm, lenght 1000mm
48-51mm, max 300 Kg hook for truss
Adaptor kit for dichroic/photographic gobos Ø 51.8 mm (for use on fixed gobo wheel)
Adaptor kit holder for dichroic/photographic gobos Ø 45 mm for use on fixed gobo wheel
Adaptor kit holder for dichroic/photographic gobos Ø 51,8 mm for use on rotating gobo wheel
Adaptor kit holder for dichroic/photographic gobos Ø 45 mm for use on rotating gobo wheel
