ROBIN® 300E Beam

Code: 10012451
ROBE Lighting

The ROBIN® 300E Beam uses a Philips MSD Gold 300/2 MiniFastFit lamp and has a beam angle of 1.6–6.5 degrees, complete with dichroic glass reflector for maximising the light output.

As with all Robe fixtures, there is a host of creative features. In additional to full colour mixing, there is a colour wheel with 7 replaceable "SLOT&LOCK" dichroic filters, plus static and rotating gobo wheels.

The ROBIN® 300E Beam has a variable frost effect for the smooth transition from a beam light to a regular wash light. Full dimming a variable strobe effect and a pan and tilt of 540/260 degrees are also onboard.

The ROBIN® 300E Beam is robustly engineered to Robe’s exacting specifications and reliability standards.


Category: moving heads , beam


  • Share:

Source

  • Lamp: Compact high-presure metal halide lamp
  • Base: PGJX28
  • Approved model: Philips MSD Gold 300/2 MiniFastFit
  • Control: Automatic and remote on/off
  • Ballast: Electronic

Optical System

  • Dichroic glass reflector for maximising the light efficiency
  • Beam angle: 6,5 ° – 1,5 °

Electrical Specification

  • Power supply: Electronic auto-ranging
  • Input voltage range: 100  –  240 V, 50/60 Hz
  • Power consumption: 420 VA at 230 V/50 Hz

Mechanical Specification

  • Height: 516 mm (20.3 ") – head in horizontal position
  • Width: 433 mm (17.0 ")
  • Depth: 458 mm (18.0 ")
  • Weight: 19.6 kg (43.0 lbs)
  • Fixation option: Pan/Tilt-lock mechanism

Thermal

  • Maximum ambient temperature: 45 °C (113 °F)
  • Maximum surface temperature: 80 °C (176 °F)

Rotating gobos

  • Glass gobos - outside diameter: 26.8 mm, max. thickness: 4.0 mm, high temperature borofloat or better glass

Control and Programming

  • Setting & Addressing: ROBE Navigation System 2 (RNS2)
  • Protocols: USITT DMX-512, RDM, ArtNet, MA Net, MA Net2
  • Control channels: 17, 19, 24
  • 3 DMX protocol modes
  • 3-editable programs, each up to 100 steps
  • Stand-alone operation
  • Display: QVGA Robe touch screen with battery backup gravitation sensor for auto screen positioning operation memory service log with RTC
  • Pan/Tilt resolution: 16 bit
  • Movement control: Tracking and vector
  • Colour wheel positioning: 8 or 16 bit
  • Static gobo wheel positioning: 8 or 16 bit
  • Rotating gobos: 8 or 16 bit
  • Frost: 8 bit
  • Focus: 8 or 16 bit
  • Dimmer: 8 or 16 bit
  • Ethernet port: Artnet protocol, ready for ACN
  • Data in/out: Locking 3-pin & 5-pin XLR
  • Built-in analyser for easy fault finding
  • Optional wireless version available: CRMX™ technology from Lumen Radio

Electromechanical Effects

  • Cyan: 0 –100 %
  • Magenta: 0 –100 %
  • Yellow: 0 –100 %
  • Colour wheel: 7 replaceable "SLOT&LOCK" dichroic filters + open, trapezoid shape
  • Static Gobo wheel: 4 gobos + 4 beam reducers
  • Rotating Gobo wheel: 7 rotating, indexable, replaceable "SLOT&LOCK" dichroic and glass gobos + open
  • Frost effect: Separate, variable
  • Dimmer/Shutter: Full range dimming and variable strobe effect, Electronic strobbing "ZAP"
  • Pan: 540 °
  • Tilt: 260 °

Rigging

  • Mounting points: 2 pairs of ¼-turn locks
  • 2x Omega bracket with ¼-turn quick locks
  • Safety chain/rope attachment point
