Alpha Wash 700

Code: C61350
Claypaky

The Alpha Wash 700 is an extraordinarily compact lightweight 700 W washlight, with the luminous efficiency, graphic and optical performance of a higher category fixture. It is extremely silent and quick, and fitted with a complete CMY colour system, special colours, 9°-50° zoom, hybrid dimmer, beam shaping filters and motorized top-hat. It is an eco-friendly light, allowing considerable running and consumption cost savings.

Diemsions


Category: moving heads , wash


  • Share:
POWER SUPPLIES

100 - 240V 50/60Hz
Automatic power supply switching

INPUT POWER

1050VA at 230V 50Hz (PFC electronic ballast)

LAMP SOURCE

700 W discharge lamp:
- Type: Philips MSR Gold 700/2 MiniFastFit
- Cap: PGjX28
- Color Temperature: 7,200 K
- Fluminous Flux: 50,000 lm
- Average Life: 750 h

OPTICS

Elliptic reflector with high luminous efficiency
Electronic linear zoom 9°-50°
Motorized Top Hat, for a perfect beam control

COLOR SYSTEM

CMY Color Mixing
Linear CTO
Color Wheel with 8 pure and selected color filters + open
CTB filter (on color wheel)

EFFECTS SECTION

Adjustable Beam Shaper (banana effect)
Adjustable "Diamond tip" lens ("X" shape)
Motorized system to zoom the beam shaper and “diamond tips" effects
A new conception 0-100% Dimmer + dimmer fine on dedicated channel.
Stop/strobe effect

CONTROL AND PROGRAMMING

Max 21 DMX 512 control channels
DMX protocol signal: USITT DMX 512
Display: Graphic LCD backlit b/w Display
Pan/Tilt Resolution: 16 bit
Dimmer Resolution: 16 bit
Movement control: vectorial
DMX signal connection: 3 and 5 pole XLR input and output
Software upload through DMX input

BODY

Aluminium structure with die-cast plastic cover.
Two side handles for transportation.
PAN and TILT lock for transport and maintenance.

MOVING BODY

Angle:
- PAN = 540°, TILT = 250°
Max Speeds:
- PAN = 3.20 sec (Normal Mode) - 2.90 sec (Fast Mode)
- TILT = 1.89 sec (Normal Mode) - 1.75 sec (Fast Mode)
Resolution:
- PAN = 2.11°, PAN FINE = 0.008°
- TILT = 0.98°, TILT FINE = 0.004°
Automatic repositioning of PAN and TILT after accidental movement not controlled by control unit.

ELECTRONICS

Long life self-charging buffer battery.
Pre-set macros.
"ENERGY SAVING" function: with the stop or total dimmer effect on, or with all the CMY filters full (black), consumption cut by 50%.
ON/OFF lamp control from the lighting desk.
Function reset from the lighting desk.
"AUTOTEST" function from menù
ETHERNET Ready.
Electronic monitoring with status error
Cooling system monitoring
DMX level monitoring on all channels
Internal data transmission diagnostics
Firmware Upgrade with no power
Firmware upload from another fixture

SAFETY DEVICES

Bipolar circuit breaker with thermal protection.
Automatic break in power supply in case of overheating.
Forced ventilation with axial fans.

WORKING POSITION

Functions in any position.
Hanging system: with fast-lock omega clamps (1/4 turn) on the base

CE MARKING

In conformity with the European Union Low Voltage Directive 2006/95/CE and Electromagnetic compatibility Directive 2004/108/CE.

ETL

This product is available, on demand, with cETLus Listed Mark, that complies with the UL 1573 and CSA C22.2 No. 166 standards.

WEIGHT

20,6 Kg (45 lbs 5 ozs)

MSR Gold 700/2 MiniFastFit (7200 K) Philips lamp

MSR GOLD 700/2 MINIFASTFIT (7200 K) PHILIPS LAMP
STANDARD
code: L10098

MSR Gold 700/1 MiniFastFit (5700 K) Philips lamp

MSR GOLD 700/1 MINIFASTFIT (5700 K) PHILIPS LAMP
OPTIONAL
code: LAM003

Standard for Alpha Profile 700 ST

HTI 700W/60/P28 Lok-it! (6000 K) Osram Lamp

HTI 700W/60/P28 LOK-IT! (6000 K) OSRAM LAMP
OPTIONAL
code: LAM005

Omega

OMEGA
STANDARD
code: 183102/805

for fixing clamps

Clamps

CLAMPS
OPTIONAL
code: C21070

48-51mm, max 300 Kg hook for truss

Safety cable

SAFETY CABLE
OPTIONAL
code: 105041/003

Ø 4mm, lenght 680mm safety cable

Foam Shell

FOAM SHELL
OPTIONAL
code: F21172

Roxter-Case

ROXTER-CASE
OPTIONAL
code: F21205

Roxter-Case for 2 Alpha 300 / 700 (2 foam shells included + wheels)

IGLOO

IGLOO
OPTIONAL
code: C61195 (with Wireless DMX receiver/transmitter) - C61198 (EASY version with no W-DMX)

Outdoor Enclosure
