Code: C61090S
Claypaky
The Alpha Profile 1200 is the most advanced 1200 W professional beam shaper on the market. In addition to its complete range of spotlight effects, it has an exclusive framing system, designed and patented by Clay Paky. This system offers never-seen-before performance, ranging from the projection of geometric figures of various shapes and sizes to a single-blade total "curtain effect". It is extremely bright, very silent and has advanced electronics and software. The Alpha Profile 1200 is a precious resource for lighting designers who work in professional environments in the theatre, television, touring and live event sectors.
Category: moving heads , spot
200 - 240V 50/60Hz
100 - 120V 50/60Hz
The power supply can be changed over with the built-in selector.
1600VA at 230V 50Hz (PFC Electronic ballast).
1200W discharge lamp
- Type: Osram Sharks HTI 1200W/D7/75
- Cap: SFc 10-4
- Color temperature: 7,500 K
- Luminous flux: 110,000 lm
- Average life: 750 h
- Hot Restrike
Elliptic reflector with high luminous efficiency
Electronic linear zoom 10°-30°
Electronic Focusing
CMY Color Mixing
6-color wheel (Ø 42mm) + open.
Linear CTO.
4 Blades that move separately.
Smooth, flexible blade movements at variable speed.
A "total curtain" effect made separately by each of the 4 blades, in many - shapes and colors.
F.M.I. effect (Framed Moving Images).
Small and large dynamic profiles.
90° rotation of the entire system, at variable speed
- 1 Rotating Gobo wheel with 6 bidirectional and indexable high-quality gobos (Ø 37,5 mm)
- 1 wheel with 8 fixed gobos (Ø 31,5mm), at variable rotation
- Selectable "Gobo shake" function.
- "Morphing" effect.
- Fixed and rotating gobos are easily interchangeable
- 1 Animation effect at variable rotation
- 1 rotating prism (9 facet).
- 2 frost filters
- high-speed mechanical iris
- 0-100% dimmer on dedicated channel
- Stop / strobe effect.
Max 35 DMX 512 control channels
DMX protocol signal: USITT DMX 512
Display: Graphic LCD Display
Pan/Tilt Resolution: 16 bit
Gobo Indexing Resolution: 16 bit
Movement control: vectorial
DMX signal connection: 3 and 5 pole XLR input and output
Software upload through DMX input
Aluminium structure with die-cast plastic cover.
Two side handles for transportation.
PAN and TILT lock for transport and maintenance.
The body of the projector can be coloured, choosing from the range of 14 colours available (minimum order: 6 pieces)
Angle:
- PAN = 450°, TILT = 252°
Max Speeds:
- PAN = 4.0 sec. (360°)
- TILT = 3.2 sec. (252°)
Resolution:
- PAN = 1.76°, PAN FINE = 0.007°
- TILT = 0.98°, TILT FINE = 0.004°
Automatic repositioning of PAN and TILT after accidental movement not controlled by control unit.
Long life self-charging buffer battery.
Pre-set macros.
Function reset from the lighting desk.
"ENERGY SAVING" function: with the stop or total dimmer effect on, or with all the CMY filters full (black), consumption cut by 50%.
115/230 V switchable power supply.
ON/OFF lamp control from the lighting desk.
"HELP", "MEMO", "AUTOTEST" functions
Possibility to upgrade the software through the DMX 512 input.
ETHERNET connection.
Electronic control on each parameter.
DMX level monitoring on each channel.
Feedback information for each sensor and encoder.
Electronic repositioning of the effects
Bipolar circuit breaker with thermal protection.
Automatic break in power supply in case of overheating.
Forced ventilation with axial fans.
Functions in any position.
Hanging system: with fast-lock omega clamps (1/4 turn) on the base
In conformity with the European Union Low Voltage Directive 2006/95/CE and Electromagnetic compatibility Directive 2004/108/CE.
This product is available, on demand, with ETLus Listed Mark, that complies with the UL 1573 standard.
39.5 Kg (86 lbs, 14 oz)
for fixing clamps
48-51mm, max 300 Kg hook for truss
Ø 4mm, lenght 680mm safety cable
Roxter-Case for 2 Alpha 1200 / Halo 1200 ( 2 foam shells included + wheels)
